| Brake tester Axle weight max. (kg) |
1000 |
| Brake tester Roller coefficient dry / wet |
> 0.6 |
| Brake tester Idling speed (km/h) |
5.5 |
| Brake tester Roller diameter (mm) |
206 |
| Brake tester Roller length (mm) |
300 |
| Brake tester Length (mm) |
560 |
| Brake tester Width (mm) |
1020 |
| Brake tester Height (mm) |
260 |
| Brake tester Weight (kg) |
150 |
| Brake tester Power supply (V/Hz) |
400 / 50 |
| Brake tester Supply lead (mm²) |
5 x 2.5 |
| Brake tester Fuse rating, slow-blow (A slow-blow) |
16 |
| Brake tester Motor power (kW) |
2.5 |
| Control cabinet (E box) width (mm) |
500 |
| Control cabinet (E box) depth (mm) |
200 |
| Control cabinet (E box) height (mm) |
650 |
| Control cabinet (E box) weight (kg) |
30 |
| Dimensions (W x D x H) (mm) |
1020 x 560 x 260 |
| Roller distance (mm) |
400 |
| Height E-Box (mm) |
650 |
| Wide E-Box (mm) |
500 |
| Depth E-Box (mm) |
200 |
| Weight E-Box (kg) |
30 |
